Frame500 Series OCLV Carbon, Full System Foil tube shaping, IsoFlow seat tube, RCS Headset System, electronic or mechanical routing, removable aero chain keeper, T47 BB, flat mount disc, UDH, 142x12 mm thru axle
ForkMadone Gen 8 full carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12x100mm chamfered thru axle
WeightML - 7.88 kg / 17.38 lbs (with TLR sealant, no tubes)
Weight limitThis bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb).
DrivetrainShimano Ultegra R8170 Di2, 12-speed
CrankShimano Ultegra R8100, 50/34
Bottom bracketPraxis, T47 threaded, internal bearing
Max. chainring size1x 54T, 2x 56/43
Wheel frontBontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready, 100x12 mm thru axle
Wheel rearBontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready, Shimano 11/12-speed freehub, 142x12 mm thru axle
Skewer frontBontrager Switch chamfered thru axle, removable lever
Skewer rearBontrager Switch chamfered thru axle, removable lever
TyreBontrager R3 Hard-Case Lite, Tubeless Ready, aramid bead, 170 tpi, 700x28 mm
Tyre partBontrager TLR sealant, 180 ml/6 oz
Max tyre size32 mm (as measured, see manual for details)
SaddleBontrager Aeolus P2 Elite
SeatpostMadone aero carbon seat post, 0 mm offset
HandlebarBontrager RSL Aero, OCLV Carbon, 31.8 mm, Di2 routing, 80 mm reach, 124 mm drop
StemTrek RCS Pro, -7-degree
Brake rotorShimano CL800, CentreLock, 160 mm
Rotor sizeMax brake rotor sizes
